WHEAT SEED GRADER CUM CLEANER

The Wheat Seed Grader Cleaner efficiently grades and cleans wheat seeds with high-capacity processing. Featuring adjustable settings for precise seed sorting and durable construction, this machine is ideal for large-scale farming operations. Easy to operate and maintain, it ensures high-quality seed preparation. Available at Murshid Farm Industries.

Detailed Description

The Wheat Seed Grader Cleaner is an essential tool for modern agriculture, designed to provide efficient and precise grading and cleaning of wheat seeds. This high-capacity machine is perfect for large-scale farming operations, ensuring that your seeds are sorted and cleaned to the highest standards.

Constructed from high-quality, durable materials, the Wheat Seed Grader Cleaner is built to withstand the rigors of continuous use in various agricultural conditions. Its robust design guarantees long-lasting performance, making it a reliable choice for farmers looking to invest in quality equipment. The durable construction also means that the grader cleaner requires minimal maintenance, allowing you to focus more on your farming activities.

One of the standout features of the Wheat Seed Grader Cleaner is its adjustable settings. These settings allow for precise control over the grading and cleaning process, ensuring that each seed is sorted accurately. The adjustable settings can be customized to suit different seed sizes and conditions, making the grader cleaner highly versatile.

The high-capacity processing capability of the Wheat Seed Grader Cleaner means that you can handle large volumes of seeds quickly and efficiently. This efficiency is crucial for large-scale farming operations where productivity and time management are essential. By ensuring that your seeds are cleaned and graded accurately, the machine helps to improve the overall quality of your seed stock, leading to better crop yields.

Designed for ease of use, the Wheat Seed Grader Cleaner is simple to operate and maintain. The intuitive controls and ergonomic design make it easy for operators of all experience levels to use the machine effectively. The straightforward maintenance requirements ensure that the grader cleaner remains in optimal working condition with minimal effort.

Murshid Farm Industries is proud to offer this high-quality Wheat Seed Grader Cleaner, along with a range of other agricultural tools and implements. As a trusted supplier of agricultural equipment, we are committed to providing products that meet the highest standards of quality and performance. Explore our offerings and find the perfect tools to enhance your farming operations.

General

Application For cleaning and grading the wheat seed

Type of Machine Tractor-trailed

Drive system 02 hp electric motor 220 V, single phase, 1460 ± 25 rpm with on/off switch and PTO drive shaft of the tractor

Cleaning/grading system Pre-sieving

Feeding hopper capacity 100 kg, with adjustable feed control

Crank displacement & strokes 23 mm @ 250 ± 5 strokes/min

Grain/fraction outlets 04 Nos. chute type

Cradle inclination control Adjustable

Aspiration blower (balanced) 1 No., paddle type

U.J. Shaft provided

Tractor power 50 hp

Cleaning/grading capacity ≥ 0.5 tons/h

Cleaning/grading efficiency ≥ 80%

Overall Dimensions

Length (with tow hook) 3000 mm ± 30 mm

Width (with wheels) 1675 mm ± 15 mm

Height (with wheels) 1500 mm ± 15 mm

Weight (Approx.) 500 kg ± 10 kg

Material Specifications

Frame M.S. channel 75 × 35 × 5 mm and M.S. angle 50 × 6 mm with diagonal braces on the top and bottom

Hopper, cradle, blower, and housing 16 gauge M.S. sheet metal

Connecting rod (adjustable) M.S. round 19 mm, cold drawn

Sieves (replaceable) 18 gauge M.S. sheet metal

Upper sieve (Metallic frame) 915 × 915 mm, holes of 3 mm dia. (10%), holes of 5 mm dia. (40%) round perforations, and 50% blind

Middle (Metallic frame) 1065 × 915 mm, holes of 3 mm dia. (80%), and holes of 3.5 mm dia. (20%) round perforations (with 80 bouncing balls and 2 mm weld/woven wire mesh screen with 12 mm pitch)

Lower Metallic frame 915 × 915 mm, 2.5 mm dia. round perforations (with 64 bouncing balls and 2 mm weld/woven wire mesh screen with 12 mm pitch)

Blower and cam-shaft 35 mm M.S. cold drawn

PTO drive shaft M.S. pipe o.d. 35 mm, wall thickness 3 mm, and length 1750 mm with universal joints

Sheaves V-groove, C.I/M.S. balanced, with 2 mm wire or expanded metal mesh cover

Transport wheels 02 Nos., 4.50 – 12 with the telescopic mounting assembly

Cradle suspension 04 Nos. 50 × 2 mm M.S. flat with bushes

Tow hitch with hook stand M.S. channel 75 × 35 × 5 mm and M.S. plate 5 mm, 20 mm M.S. hook and 50 × 5 mm M.S. square box stand with brackets and grease system

Bearings Cam Shaft Cam Connecting rod Blower   02 Nos. UCP 207 01 No. 6215 02 Nos. 6205 02 Nos. 6206

Wheels 02 Nos. 6206 & 02 Nos. 6205

Miscellaneous

Paint Double coat with primer after the surface finish

Bearings European Standard or equivalent

Nuts and bolts To be tightened with spring washers

Warranty Free: 1 year for parts and service Extended: 5 years for parts supply on payment
